BVS-220 Vertical Single Lane Stick Bag Packing Machine
contact usTechnical Parameter
Boevan BVS series Vertical Packing Machine is designed for stick bag forming filling and sealing. It can automatic packaging machine can automatically complete the multi column automatic quantitative measurement packing.
Want to know more about vertical packaging machines? Click the following content to view
| Model | Pouch Width | Pouch Length | Filling Capacity | Packaging Capacity | Weight | Film width | Lanes No | Speed(Bag/min) | Machine Dimensions(L*W*H) |
| BVS-220 | 20-70mm | 50-180mm | 100ml | 25-40ppm | 400kg | 220mm | 1 | 40 | 815×1155×2285mm |
Packing Process
- 1Date code printer
- 2Straight line cut with easy tear
- 3Piston pump (for liquid or cream)
- 4Round corner function
- 5Shape sealig function
Optional Filling Device
- 1Servo Auger Filler(for powder)
- 2Volumetric cup filler(for granule)
- 3Pistion pump(for liquid or cream)
★Different products and packing volume will cause speed variation.
Product Details
Auto Film-aligning System
Automatically align film position during machine operation, avoid the problem of pouch sealing misalignment.
Servo Pouch-Pulling System
Easy computerized specification change over, stable pouch pulling with less deviation, large torquemoment qualified for full-load running.
Integrated Core Control System
PLC, Touch screen, Servo and Pneumatic system compose the drive and control system with higher integration, accuracy and reliability.
Product Application
BVS Series is available in 1 lane and 2 lanes, depending on speed and bag width.
- ◉Powder
- ◉Granule
- ◉Viscosity
- ◉Solid
- ◉Liquid
- ◉Tablet
