BHD-280DSC Duplex Horizontal Spout Doypack Packing Machine

BHD-280DSC Boevan Horizontal Duplex Doypack Packing Machine With Spout Function series doypack function & duplex design with max speed 120ppm. With additional functions of hanging hole, special shape, zipper and spout, can pack powder, granule, liquid, sauce.

The pouch width range that the packing machine can make is 90-140mm, the pouch length range that the packing machine can make is 110-250mm, the maximum filling capacity is 500ml, and the packaging speed is about 80-100ppm.

PRODUCT DETAIL

Video

Technical Parameter

BHD-280DSC HFFS Machine for Duplex Spout Pouch Form Fill Seal Packing. Center Spout or Corner Spout can be choise.

Model	Pouch Width	Pouch Length	Filling Capacity	Packaging Capacity	Function	Weight	Power	Air Consumption	Machine Dimensions(LWH)
BHD-280DSC	90- 140mm	110-250mm	500ml	80-100ppm	DoyPack, Shape, Hanging Hole, Zipper	2150kg	15.5kw	400 NL/min	7736×1300×1878mm

Packing Process

1Film Unwinding Device
2Zipper Roll
3Bag Forming Device
4Photocell
5Zipper Horizontal Seal
6Zipper Vertical Seal
7Bottom Seal Unit
8Vertical Seal
9Tear Notch
10Servo Pulling System
11Cutting Knife
12Pouch Opening
13Air Flushing Device
14Filling Ⅰ
15Filling Ⅱ
16Pouch Stretching
17Top Sealing
18Outlet

Product Advantage

Servo Advance System

Easy computerized specification change
Stable pouch advance with less deviation
Big torquemoment of pouch advance, suitable for big volume

Photocell System

Full spectrum detection, Accurate detection of all light sources
High speed motion mode

Spout Function

Even spout seal with good appearance
High spout seal strength, no leakage

Product Application

BHD-280D Series hffs machine doypack function & duplex design with Max speed 120ppm. With additional functions of hanging hole, special shape, zipper and spout .
