BHP Duplex Horizontal Premade Bag Packing Machine

Boevan BHP Duplex Horizontal Premade Pouch Packing Machine Series designed for pre-made bag to filling and sealing packing.

This type of the premade packing machine has dual filling station, can reduced filling time by half and improved filling accuracy, has 3-pair top seal unit to ensure seal strength, even seal with good appearance. Also has air flushing device, can auxiliary flushing, improved bag opening success rate, can detected function, if bag opening not good, no filling, no sealing!

PRODUCT DETAIL

Technical Parameter

Boevan BHP series Premade Pouch Packing Machine is a horizontal type pre-made pouch filling and sealing machine can be used for doypack, flat pouch, zipper bag, spout pouch packaging packing. This packaging machine is not limited to packaging liquids, pastes, powders, granules, blocks, capsules, tablets and other products. It is currently widely used in major industries such as medicine, daily chemicals, food and beverages.

Model	Pouch Width	Pouch Length	Filling Capacity	Packaging Capacity	Function	Weight	Power	Air Consumption	Machine Dimensions(LWH)
BHP-210D	75- 105mm	1 10-300mm	400ml	80- 100ppm	Flat Pouch, DoyPack	1100kg	4.5 kw	200 NL/min	3216×1190×1422mm
BHP-280D	90- 140mm	1 10-300mm	600ml	80- 100ppm	Flat Pouch, DoyPack	2150kg	4.5 kw	500 NL/min	4300×970×1388mm
BHP-280DZ	90- 140mm	1 10-300mm	600ml	80- 100ppm	Flat Pouch , DoyPack , Zipper	2150kg	4.5 kw	500 NL/min	4300×970×1388mm
