BHD-280DSZ

BHD-280DSZ Featured Image

BHD-280DSZ

BHD-280DS Boevan Horizontal Duplex Zipper Doypack Packing Machine series doypack function & duolex design with max speed 120ppm. With addition functions of hanging hole, special shape, zipper and spout.

The pouch width range that the machine can make is 90-140mm, the pouch length range is 110-250mm, and the maximum filling capacity is 500ml, the packing capaaity is about 80-100ppm.

The machine has duplex design can stable operation and easy to adjustment, improved productivity. Also has photocell system can accurate detection of all light sources and has high speed motion mode.

contact us

PRODUCT DETAIL

Technical Parameter

Model	Pouch Width	Pouch Length	Filling Capacity	Packaging Capacity	Function	Weight	Power	Air Consumption	Machine Dimensions(LWH)
BHD-280DSZ	90- 140mm	110-250mm	500ml	80-100ppm	DoyPack, Shape, Hanging Hole, Spout	2150kg	15.5kw	400 NL/min	8200×1300×1878mm

Packing Process

BHD-280DSDSZDSC

1Film Unwinding Device
2Zipper Roll
3Bag Forming Device
4Photocell
5Zipper Horizontal Seal
6Zipper Vertical Seal
7Bottom Seal Unit
8Vertical Seal
9Tear Notch
10Servo Pulling System
11Cutting Knife
12Pouch Opening
13Air Flushing Device
14Filling Ⅰ
15Filling Ⅱ
16Pouch Stretching
17Top Sealing
18Outlet

Product Advantage

Duplex Design

Duplex Design

Stable operation,easy adjustment
2 pouches at the same time, double productivity

Photocell System

Photocell System

Full spectrum detection, Accurate detection of all light sources
High speed motion mode

Zipper Function

Zipper Function

Independent zipper unwind device
Stable zipper tensile force control
Even zipper seal

Product Application

BHD-280D Series doypack function & duplex design with Max speed 120ppm. With additional functions of hanging hole, special shape, zipper and spout.

◉Powder
◉Granule
◉Viscosity
◉Solid
◉Liquid
◉Tablet

zipper pouch (2)

zipper pouch (3)

zipper pouch (4)

zipper pouch (1)

zipper pouch (5)

zipper pouch (6)
