Technical Parameter
| Model | Pouch Width | Pouch Length | Filling Capacity | Packaging Capacity | Function | Weight | Power | Air Consumption | Machine Dimensions(L*W*H) |
| BHD- 130S | 60- 130mm | 80- 190mm | 350ml | 35-45ppm | DoyPack,Shape | 2150 kg | 6 kw | 300NL/min | 4720mm×1 125mm×1550mm |
Packing Process
- 1Film Unwinding
- 2Bottom Hole Punching
- 3Bag Forming Device
- 4Film Guide Device
- 5Photocell
- 6Bottom Seal Unit
- 7Vertical Seal
- 8Tear Notch
- 9Servo Pulling System
- 10Cutting Knife
- 11Pouch Opening Device
- 12Air Flushing Device
- 13Filling Ⅰ
- 14Filling Ⅱ
- 15Pouch Stretching
- 16Top Sealing Ⅰ
- 17Top Sealing Ⅱ
- 18Outlet
Product Advantage
Servo Advance System
Easy computerized specification change
Stable pouch advance with less deviation
Big torquemoment of pouch advance, suitable for big volume
Photocell System
Full spectrum detection, Accurate detection of all light sources
High speed motion mode
Shape Function
Special shape bar design
Vertical stand reduces fuel consumption
Product Application
BHD-130S/240DS Series designed for doypack, with functions of making hanging hole, special shape, zipper and spout.
- ◉Powder
- ◉Granule
- ◉Viscosity
- ◉Solid
- ◉Liquid
- ◉Tablet
